Versions
AH12
- Tooth pitch 12 TPI (2.25 mm)
- Standard rule for light-weight singlewall and micro-flute corrugated board
- Ideal for cutting foam
AH8
- Tooth pitch 8 TPI (3.0 mm)
- For easy penetration even with the toughest corrugated board
- Precise cutting of double and triple wall corrugated cardboard as well as honeycomb cardboardAH12
Specifications
- Thickness: 4 pt (1.42 mm) | 3 & 6 pt on request
- Heights: 23.8 - 31.75 mm
- Availability: coils and metre lengths
- Packaging Unit: 50 m
Hardness
- Body: 32 - 34 HRC
- Cutting Edge: > 52 HRC
Cutting Forms
Forms
Coil Directions
